Vsmile C518DW: All-in-One Dry & Wet Milling Solution
Vsmile C518DW: The Future of Dental Milling Is Now
Integrated dry & wet CAD/CAM milling
Titanium, zirconia, PMMA, glass ceramics, PEEK – All covered
Up to 5μm repetition accuracy and water-cooled 2.5kW spindle
According to recent reports by Fortune Business Insights and Verified Market Reports, the global CAD/CAM dental milling machine market is projected to grow significantly due to rising demand for aesthetic restorations, increased chairside production, and digital workflow adoption. However, many labs are struggling with equipment fragmentation, limited milling capabilities, or inefficient switching between wet and dry modes.
Enter the Vsmile C518DW — a game-changing 5-axis milling machine designed to unify all your workflows. Whether you’re cutting titanium bars, zirconia bridges, or lithium disilicate crowns, the C518DW delivers industry-leading performance from a single unit.
Why C518DW? Solving the Real Problems Dental Labs Face
- Material Overlap: No more switching machines — mill glass ceramics and titanium in one place
- Workflow Bottlenecks: Automate calibration, tool monitoring, and drying without delays
- Precision Issues: Achieve consistent 5μm repeatability with advanced mechanics
- Production Downtime: Smart water cooling and 18-tool auto changer maximize uptime
- Space Constraints: Compact aluminum body, powerful performance
Key Technical Highlights
- Wet & Dry Integrated Milling
- 2.5kW Water-Cooled Spindle, 60,000 RPM
- Repositioning Accuracy: 0.005 mm
- 18-Tool Auto Changer with Lifetime Monitoring
- Internal Camera + LCD Touch Panel
- 5 Axis Movement: A ±360°, B +30° ~ -90°
- Max Disc Size: 98 x 35mm
- Remote monitoring via networked system
FAB Table: Feature – Advantage – Benefit
| Feature | Advantage | Benefit |
|---|---|---|
| Dry & Wet Integrated Milling | Eliminates machine switching | Streamlined workflow & cost efficiency |
| 2.5kW Water-Cooled Spindle | High performance + cooling stability | Supports long-duration, complex milling |
| 5-Axis Simultaneous Milling | Multi-angle machining with one clamp | Perfect contours for abutments, bridges |
| 18-Tool Auto Changer | Smart tool replacement with monitoring | Reduces manual errors, boosts uptime |
| Automatic Calibration | Precise tool positioning | Fewer remakes, higher reliability |
| 98mm / 35mm Disc Support | Handles full-arch and large restorations | Expand your case range easily |
Applications
The C518DW covers almost every dental milling case: Crown / Bridge, Inlay / Onlay, Veneer, Denture, Screw-retained Bridge, Implant Bar, Surgical Guide, Abutments, and more.
Technical Specifications
| Dimensions | 525 × 700 × 784 mm | Weight | 150 kg |
| Spindle Speed | 60,000 RPM | Spindle Power | 2.5kW |
| Axis Control | A ±360°, B +30°~ -90° | Precision | 0.01mm / 0.005mm repeat |
| Collet | 6mm | Water Tank | 10L |
| Power Supply | 220V / 3.2kW | Air Pressure | >0.5 MPa / >90 L/min |
Want to transform your lab’s efficiency? Contact us now to learn how the C518DW can streamline your digital workflow.
? Email: info@dentalzirconiadisc.comm| ? Website: www.vsmilecadcam.com
