Vsmile Milling BursDentium ® Compatible
Always Choosing The Best Tools for the Best Results
VsmileHigh performance milling tools designed and engineered specifically for the digital dentistry sector
Compatible With Dentium For Zirconia/PMMA/Wax Milling | |||
Shank Dia.(mm) | 3.0 | 3.0 | 3.0 |
Head Dia.(mm) | 2.0 | 1.0 | 0.5 |
Overlength(mm) | 50 | 50 | 42 |
Coating | Diamond/Diamond Liked/Uncoated/Rainbow | ||
Compatible With Dentium For Emax/Glass Ceramic/Lithium Disilicate Milling | |||
Shank Dia.(mm) | 4.0 | 4.0 | 4.0 |
Head Dia.(mm) | 2.0 | 1.0 | 0.6 |
Overlength(mm) | 45 | 45 | 45 |
Shank Dia.(mm) | 6.0 | 6.0 | 6.0 |
Head Dia.(mm) | 2.0 | 1.0 | 0.5 |
Overlength(mm) | 50 | 50 | 50 |
Compatible With Dentium For Metal Milling | |||
Shank Dia.(mm) | 6.0 | 6.0 | 6.0 |
Head Dia.(mm) | 2.0 | 1.0 | 0.6 |
Overlength(mm) | 50 | 50 | 50 |
Head Shape | Ball End | ||
Coating:
CVD German coating / DC （Diamond Coating） / DLC（DiamondLiked Coating ）
Characteristics:
1. DLC coating mlling tool can mill 120 to 150 units teeth.
2. DC coating milling tool can mill 300 to 500 units teeth.
3.CVD coating mlling tool can mill 500 to 800 units teeth.
3. All our burs are made by the optimal tungsten carbide material and stainless steel.
Model:
Dentium Rainbow™ Mill-Zr
Dentium Rainbow™ Mill-Clinic
Dentium Rainbow™ Mill-Metal
Material: Tungsten Steel
Coating:CVDDiamond Coating / PVD Diamond Coating / DiamondLiked Coating / Professional Coating for Emax grinding
Packaging: Individually packing
CAD/CAM Dental Milling BurCompatible With Dentium
- Long life span
- Excellent surface quality
- Precise milling performance and results
Tool to the bottom line
We understand the implication of tool life on the financial bottom line. This is why our tools have been designed to last longer resulting in a lower cost per crown.
Tools to machines
In order to support end users to create the optimal performance we have worked with Dentiumauthorised software providers to develop downloadable ‘tool sets’ to ensure that machines are calibrated to Vsmile Digital tools.
Restoration to Mouth Increased
precision in milling restorations will result in less need for dentists to complete chair-side modifications - therefore a better fit.
Restoration to CAD Design
Our tools mill restorations highly precisely and have been engineered to result in the highest likeness to the CAD design.
